PRODUCT FEATURES
• Power size: Fixed power, Size 3
• Body material: Aluminium
• Arm set type / material: Slide track / Aluminium; Connecting arm / Steel
• Functions: Closing speed, Latching speed
• Maximum door weight: 60kgs
• Maximum door width: 950mm
• Performance Testing: Successfully tested in accordance with the requirements of BS EN1154: 1997
Classification: Door mount pull side only
FIRE TESTING• Successfully fire tested in accordance with the requirements of BS EN1634-1, suitable for use on 30-minute Timber fire doors
CERTIFICATION
• UKCA marked (Certificate AD7996)
• CE marked (Certificate AD7995)
• CERTIFIRE approved (Certificate CF6158)
OPTIONS
• Hold open kit (NOT TO BE USED ON FIRE RATED DOORS)
INTUMESCENT
• (ZDC003-INT/KIT) 1mm / 2mm graphitekit for 30-minute timber fire rated doors
FINISHES
• Silver (SE)
*Other finishes available on request
